Kedro

See all of my kedro related posts in [[ tag/kedro ]].

#kedrotips ¶ #

I am tweeting out most of these snippets as I add them, you can find them all here #kedrotips.

🗣 Heads up ¶ #

Below are some quick snippets/notes for when using kedro to build data pipelines. So far I am just compiling snippets. Eventually I will create several posts on kedro. These are mostly things that I use In my everyday with kedro. Some are a bit more essoteric. Some are helpful when writing production code, some are useful more usefule for exploration.

📚 Catalog ¶ #

CSVLocalDataSet ¶ #

python

import pandas as pd
iris = pd.read_csv('https://raw.githubusercontent.com/kedro-org/kedro/d3218bd89ce8d1148b1f79dfe589065f47037be6/kedro/template/%7B%7B%20cookiecutter.repo_name%20%7D%7D/data/01_raw/iris.csv')

data_set = CSVLocalDataSet(filepath="test.csv",
                                 load_args=None,
                                 save_args={"index": False})

iris_data_set.save(iris)
reloaded_iris = iris_data_set.load()

yaml

test_data:
   type: CSVLocalDataset
   filepath: test.csv
   load_args: None
   save_args:
      index: False

CSVHTTPDataSet ¶ #

cities = CSVHTTPDataSet(
    fileurl="https://raw.githubusercontent.com/kedro-org/kedro/d3218bd89ce8d1148b1f79dfe589065f47037be6/kedro/template/%7B%7B%20cookiecutter.repo_name%20%7D%7D/data/01_raw/iris.csv",
    auth=None,
    load_args=None)

iris = iris_data_set.load()

cities:
   type: CSVHTTPDataSet
    fileurl: https://people.sc.fsu.edu/~jburkardt/data/csv/cities.csv
    auth: None
    load_args: None

HDFLocalDataSet ¶ #

import pandas as pd
from kedro.io import HDFLocalDataSet

iris = pd.read_csv('https://raw.githubusercontent.com/kedro-org/kedro/d3218bd89ce8d1148b1f79dfe589065f47037be6/kedro/template/%7B%7B%20cookiecutter.repo_name%20%7D%7D/data/01_raw/iris.csv')
iris_data_set = HDFLocalDataSet(filepath="iris.hdf",
                           key="test_hdf_key",
                           load_args=None,
                           save_args=None)

iris_data_set.save(iris)
reloaded_iris = iris_data_set.load()

cars:
   type: HDFLocalDataSet
   filepath: test.hdf
   key: test_hdf_key

HDFS3LocalDataSet ¶ #

import pandas as pd
from kedro.io import HDFS3DataSet

iris = pd.read_csv('https://raw.githubusercontent.com/kedro-org/kedro/d3218bd89ce8d1148b1f79dfe589065f47037be6/kedro/template/%7B%7B%20cookiecutter.repo_name%20%7D%7D/data/01_raw/iris.csv')
iris_data_set = HDFS3DataSet(filepath="iris.hdf",
                        bucket_name="bucket-us-west-1",
                        key="test_hdf_key",
                        load_args=None,
                        save_args=None)

iris_data_set.save(iris)
reloaded_iris = iris_data_set.load()

cars:
   type: HDFS3DataSet
   filepath: cars.hdf
   bucket_name: bucket-us-west-1
   key: test_hdf_key

JSONLocalDataSet ¶ #

import pandas as pd
from kedro.io import JSONLocalDataSet

iris = pd.read_csv('https://raw.githubusercontent.com/kedro-org/kedro/d3218bd89ce8d1148b1f79dfe589065f47037be6/kedro/template/%7B%7B%20cookiecutter.repo_name%20%7D%7D/data/01_raw/iris.csv')
cars = JSONLocalDataSet(filepath="iris.json",
                        load_args=None,
                        save_args=None)

iris_data_set.save(iris)
reloaded_iris = iris_data_set.load()

cars:
   type: JSONLocalDataSet
   filepath: iris.json

ParquetLocalDataSet ¶ #

import pandas as pd
from kedro.io import ParquetLocalDataSet

iris = pd.read_csv('https://raw.githubusercontent.com/kedro-org/kedro/d3218bd89ce8d1148b1f79dfe589065f47037be6/kedro/template/%7B%7B%20cookiecutter.repo_name%20%7D%7D/data/01_raw/iris.csv')

iris_data_set = ParquetLocalDataSet('iris',
                           engine='auto',
                           load_args=None,
                           save_args=None,
                           version=None)

iris_data_set.save(iris)
reloaded_iris = iris_data_set.load()

cars:
   type: JSONLocalDataSet
   filepath: cars

PickleS3DataSet

SQLTableDataSet

SQLQueryDataSet

TextLocalDataSet

ExcelLocalDataSet

⏳ Loading Data ¶ #

Simple Loading ¶ #

df = catalog.load('cars')

list all datasets ¶ #

catalog.list()

Saving Data ¶ #

catalog.save('cars', cars)

🔍 Finding data ¶ #

simple keyword search

query = 'raw'
[data for data in catalog.list() if query in data]

see on #kedrotips

multi keyword serch

query = 'raw sales'
data_sets = catalog.list()
for word in query.split():
 data_sets = [
       data
       for data in data_sets
       if query in data
       ]

see on #kedrotips

🐒 monkey patch it

def query(*search_terms):
     data_sets = catalog.list()
     for search in search_terms:
         data_sets = [
         data
         for data in data_sets
         if search in data
         ]
     return data_sets

catalog.query = query

_see on #kedrotips

🤙 YOLO ¶ #

You Only Load Once

simple

data = [catalog.load(d)
        for d in
        catalog.query('c_pri', 'cars')
        ]

more refined

data = {
   d: catalog.load(d)
   for d in catalog.query('c_pri', 'cars')
   }

🍷 refined like a fine wine

from types import SimpleNamespace
data = SimpleNamespace**{
   d: catalog.load(d)
   for d in catalog.query('c_pri', 'cars')
   })

🧀 Make it a function getting funcy

from types import SimpleNamespace

def yolo(*search_terms):
   """you only load once
   using query method from previous tip"""
   data = SimpleNamespace(**{
       d: catalog.load(d)
   for d in catalog.query(*search_terms)
    })
    return data

all_pri = yolo('c_pri')

🐒 monkey patch it

from functools import partial

catalog.yolo = yolo
catalog.yolo.__doc__ = "you only load once"

all_pri = catalog.yolo('c_pri')

adding catalogs together ¶ #

from kedro.io import DataCatalog
DataCatalog({**cat1.__dict__['_data_sets'], **cat2.__dict__['_data_sets']})

🛢 Building pipelines ¶ #

📍 Creating Nodes ¶ #

from kedro.pipeline import node
node = node(lambda x: x.dropna(), inputs='raw_cars', outputs='int_cars')

from kedro.pipeline import node

def drop_columns(df, *columns):
   for column in columns:
      df = df.drop(columns=column)
   return df

node = node(
   lambda x: drop_columns(x, 'vs', 'am', 'gear', 'carb'),
   inputs='int_cars',
   outputs='pri_cars'
   )

🛢 Creating a pipeline ¶ #

Don’t be so verbose ¶ #

Create similar nodes dynamically

def halve_dataframe(data: pd.DataFrame) -> List[pd.DataFrame]:
   """ splits a dataframe in half """
    return np.array_split(data, 2)

nodes = []
datasets = [
   'cars', 'trucks', 'boats', 'motorcycles', 'planes',
   'ships', 'busses', 'trains', 'subways'
   ]

# creates a pipeline node for every dataset in the datasets list
for dataset in datasets
   nodes.append(
       node(halve_dataframe,
            'e_modin_{dataset}',
            ['train_{dataset}', 'test_{dataset}']),
   )

🏃‍♂️ Running Pipelines ¶ #

🔖 filter by tags

nodes = pipeline.only_nodes_with_tags('cars')

see on #kedrotips

filter by node

nodes = pipeline.only_nodes('b_int_cars')

_see on #kedrotips

filter nodes like

query_string = 'cars'
nodes = [
   node.name
   for node in pipeline.nodes
   if query_string in node.name
   ]
pipeline.only_nodes(*nodes)

see on #kedrotips

only nodes with tags or

nodes = pipeline.only_nodes_with_tags('cars', 'trains')

only nodes with tags and

raw_nodes = pipeline.only_nodes_with_tags('raw')
car_nodes = pipeline.only_nodes_with_tags('cars')
raw_car_nodes = raw_nodes & car_nodes

raw_nodes = (
   pipeline
   .only_nodes_with_tags('raw')
   .only_nodes_with_tags('cars')
   )

add pipelines

car_nodes = pipeline.only_nodes_with_tags('cars')
train_nodes = pipeline.only_nodes_with_tags('trains')
transportation_nodes = car_nodes + train_nodes

ensure nodes are attached

cars_attached = len(
   pipeline
   .only_nodes_with_tags('cars')
   .grouped_nodes
   ) == 1

🎂 Pipeline Decorators ¶ #

example - log_time

from kedro.pipeline.decorators import log_time, mem_profile
pipeline.decorate(log_running_time)

Pipeline IO ¶ #

pipleine.all_inputs() and pipeline.all_outputs() return sets of pipeline inputs and outputs and you can do set operations on them. This is particularly useful to find the upper and lower edges of your pipeline or subset of pipeline. The pipeline object here is any kedro pipeline including a filtered subset.

Find all raw data ¶ #

pipeline.all_inputs() - pipeline.all_outputs()

Find all final data ¶ #

pipeline.all_outputs() - pipeline.all_inputs()

Find all nodes that do not raw ¶ #

This one is probably one that is pushing the limits of what I would do in a list comprehension that I use in prod or even put into a text editor, but I commonly use ipython for my adhoc work and keeping it all in one line is very handy. Complex list comprehensions kinda start becoming like regex in a way that they are really easy to write and really hard to read. I don’t think this one quite hits that point but its getting close.

I find this one super useful to help me either move data beween environments, or avoid unnecessary database calls.

raw_inputs = pipeline.all_inputs() - pipeline.all_outputs()
raw_nodes = [node for node in pipeline.nodes if [i for i in raw_inputs if i in set(node.inputs)] != []]
